Home / All / Metalworking Machinery / Metal Cutting Machine / Fiber Laser Cutting Machine / Customizable CNC Fiber Laser Cutting Machine | RONGWIN Sheet and Tube Metal Cutter
Customizable CNC Fiber Laser Cutting Machine | RONGWIN Sheet and Tube Metal Cutter
Customizable CNC fiber laser cutter for sheet and tube. 100m/min speed, 0.03mm precision, 3-year warranty.
| Share | |
|---|---|
| Categories | Fiber Laser Cutting Machine |
| Brand | MetalWorkMaster Smart Custom Metal Solution Expert |
| Model | fiber laser cutting machine |
| Laser Type | Fiber Laser |
| Applying Materials | Metal Fiber laser Cutting Machine |
| Degree of oldness | New |
| Country of origin | China |
| Industrial laser brand | IPG |
| Core selling point | Long Service Life |
| Warranty | 3 years |
| Operation Mode | Pulsed |
| Configuration | Gantry Type |
| Product handling | Sheet Metal and Tube |
| Unit Price | US $ 30000-100000 / piece |
| FOB port | shanghai |
| Terms of Payment | L/C, T/T |
Detail Information
Customizable CNC Fiber Laser Cutting Machine for Sheet Metal and Tube Processing
The RONGWIN customizable CNC fiber laser cutting machine is engineered for high-precision sheet metal and tube processing across stainless steel, carbon steel, aluminum, and brass. Featuring an IPG fiber laser source and Cypcut CNC control system, this gantry-type machine delivers cutting speeds up to 100m/min with positioning accuracy of ≤±0.03mm.
With 10 model series ranging from RWL-3015B to RWL-130225G, the machine accommodates processing areas from 3000×1500mm up to 13000×2500mm. Laser power options span from 1500W to 30000W, enabling customizable configurations for diverse metal fabrication requirements.
- IPG fiber laser source with long service life
- Cypcut CNC control system for precise operation
- Gantry-type configuration for sheet metal and tube
- 3-year warranty with pulsed operation mode
Key Features of the CNC Fiber Laser Cutting Machine
High-Speed Cutting up to 100m/min
Maximum positioning speed of 120m/min enables efficient metal processing, significantly reducing production time for high-volume fabrication workflows.
Precision Accuracy ≤±0.03mm
X/Y-axis positioning accuracy of ≤±0.03mm and repeat positioning accuracy of ≤±0.02mm ensure consistent, high-quality cutting results across all materials.
Sheet Metal and Tube Processing
Dual-purpose design handles both sheet metal and tube cutting. Compatible with stainless steel, carbon steel, aluminum, brass, and copper materials.
Customizable Laser Power and Bed Size
Ten model series from RWL-3015B to RWL-130225G with laser power options from 1500W to 30000W. Configurable processing range from 3000×1500mm to 13000×2500mm.
IPG Fiber Laser Source
Industrial-grade IPG fiber laser delivers stable beam quality and long service life. Pulsed operation mode provides optimal cutting performance for varied material thicknesses.
Cypcut CNC Control System
Advanced Cypcut CNC system offers intuitive operation, real-time monitoring, and optimized cutting path planning for maximum efficiency and precision.
Technical Specifications of the Fiber Laser Cutting Machine
The following specification table details all 10 model series of the RONGWIN fiber laser cutting machine, including processing range, axis travel distances, laser power options, and accuracy ratings.
| Model Series | Processing Range | X-axis Travel | Y-axis Travel |
|---|---|---|---|
| RWL-3015B | 3000*1500mm | 1500mm | 3000mm |
| RWL-4015B | 4000*1500mm | 1500mm | 4000mm |
| RWL-4020B | 4000*2000mm | 2000mm | 4000mm |
| RWL-6015B | 6000*1500mm | 1500mm | 6000mm |
| RWL-6020B | 6000*2000mm | 2000mm | 6000mm |
| RWL-6322B | 6300*2200mm | 2200mm | 6300mm |
| RWL-6325B | 6300*2500mm | 2500mm | 6300mm |
| RWL-8322B | 8300*2200mm | 2200mm | 8300mm |
| RWL-8325B | 8300*2500mm | 2500mm | 8300mm |
| RWL-130225G | 13000*2500mm | 2500mm | 13000mm |
| Specification | Value |
|---|---|
| Z-axis Travel | 140mm |
| Laser Power | 1500/2000/3000/4000/6000/8000/10000/12000/15000/20000/30000/others |
| X/Y-axis Positioning Accuracy | ≤±0.03mm |
| X/Y-axis Repeat Positioning Accuracy | ≤±0.02mm |
| Maximum Positioning Speed | 120m/min |
Industrial Applications of the Metal Fiber Laser Cutting Machine
The RONGWIN CNC fiber laser cutting machine serves diverse industries including automotive manufacturing, aerospace, construction machinery, electrical equipment, and metal fabrication. The following images demonstrate real-world cutting applications and sample outputs.
Automotive Component Cutting
Construction Steel Fabrication
Stainless Steel Processing
Electrical Equipment Manufacturing
Tube and Sheet Metal Fabrication
Cutting Samples and Quality Results
RONGWIN Manufacturing Expertise and Quality Assurance
Experienced Laser Machine Manufacturer
RONGWIN specializes in CNC fiber laser cutting machine manufacturing with extensive industry experience. The gantry-type configuration is engineered for long service life and reliable performance in demanding production environments.
IPG Laser and Cypcut CNC Authority
The machine integrates IPG industrial laser technology and Cypcut CNC control system, representing industry-leading brands in fiber laser cutting. Pulsed operation mode ensures optimal cutting quality across material types and thicknesses.
3-Year Warranty and Technical Support
Backed by a comprehensive 3-year warranty, the RONGWIN fiber laser cutting machine includes ongoing technical support. All machines undergo rigorous quality testing before shipment to ensure specification compliance.
Quality Certifications and Global Export
Manufactured in China to international quality standards, RONGWIN laser cutting machines are exported globally. Each model series meets stringent accuracy and performance specifications for industrial metal fabrication.
Frequently Asked Questions About the Fiber Laser Cutting Machine
What materials can the RONGWIN fiber laser cutting machine process?
The machine processes stainless steel, carbon steel, aluminum, brass, and copper. It handles both sheet metal and tube with the gantry-type configuration. Laser power options from 1500W to 30000W accommodate material thicknesses from thin sheets to thick plates.
What laser power options are available for the CNC fiber laser cutting machine?
Available laser power options include 1500W, 2000W, 3000W, 4000W, 6000W, 8000W, 10000W, 12000W, 15000W, 20000W, 30000W, and custom configurations. The IPG fiber laser source ensures stable beam quality across all power levels.
What warranty is included with the customizable laser cutting machine?
The RONGWIN fiber laser cutting machine includes a 3-year warranty covering the laser source, CNC system, and mechanical components. The machine uses pulsed operation mode with an IPG laser source designed for long service life.
Can the sheet and tube laser cutter be customized for specific needs?
Yes. Ten model series from RWL-3015B to RWL-130225G offer processing ranges from 3000×1500mm to 13000×2500mm. Customers can select laser power, bed size, and configuration options to match specific production requirements.
What CNC control system does the metal laser cutting machine use?
The machine uses the Cypcut CNC control system, providing intuitive operation, real-time cutting monitoring, and optimized path planning. The system achieves positioning accuracy of ≤±0.03mm and repeat accuracy of ≤±0.02mm.
Request a Custom Quote for Your Fiber Laser Cutting Machine
Contact RONGWIN to configure your customizable CNC fiber laser cutting machine. Select from 10 model series, laser power from 1500W to 30000W, and processing ranges up to 13000×2500mm. 3-year warranty included.
