Home / All / Metalworking Machinery / Metal Forming Machine / Hydraulic Press / Hydraulic press | Accurate bending and forming
Hydraulic press | Accurate bending and forming
The hydraulic press provides precise, stable, and efficient sheet metal bending for various applications.
- Price
- US $
12000-11000
- Model
- 350 ton hydraulic press
- Unit Price
Order Quantity Unit Price Delivery period 1 - 4 US $12000.0/piece 15 day 5 - 10 US $11000.0/piece 30 day
- Quantity
Detail Information
- System:PLC
- Condition:New
- Place of Origin:China
- Weight:10 T
- Applicable Industries:Building Material Shops, Machinery Repair Shops,Ma
- Marketing Type:New Product 2024
- Machinery Test Report:Provided
Hydraulic Press Introduction
Hydraulic Press : Precision Bending for Metal Sheets
The hydraulic press forms metal sheets using hydraulic pressure, suitable for precision machining of both thin and thick plates. Widely used in sheet metal, automotive, aerospace, and construction industries. Features include uniform pressure for precise results, versatility for various angles and shapes, and CNC control for high-precision.
Hydraulic Press Application Scenario
Hydraulic Press Advantages
Feature 1
Machine body
1. Machine body: all machining by VMC machine center , making sure the high working accuracy .
2.The four column all adopt 45 steel material , by forging making after quenching and chromium plating .
3.The main cylinder rod making by forging process and adopt SKF seals , making sure lone use life .
Feature 2
System
1. 350-ton hydraulic system: Provides powerful hydraulic power to ensure the ability to handle large-size and high-strength materials.
Hydraulic Press Technical Parameters
350 ton hydraulic press offers a variety of models, covering a variety of needs from small to large, the specific technical parameters range as follows:
Parameters | Liquid pressure (mpa) | Piston travel (mm) | Gantry span (mm) | Worktablesize(L-R)*(F- B) （mm) | Motor power (kw) | Descent speed (mm） | Return speed （mm） |
|
20TA
|
18
|
200
|
420
|
360*400 | 2.2 | 12 | 19 |
|
20TB
|
18
|
200
|
420
|
360*400 | 3 | 21 | 32 |
40TA | 23 | 200 | 500 | 400*460 | 3 | 6.5 | 9.5 |
40TB | 23 | 200 | 500 | 400*460 | 5.5 | 14 | 19 |
60TA | 30 | 200 | 500 | 400*460 | 6 | 6 | 8 |
60TB | 30 | 200 | 500 | 400*460 | 5.5 | 12 | 16 |
80TA | 31.5 | 240 | 520 | 500*450 | 5.5 | 9 | 13 |
80TB | 31.5 | 240 | 520 | 500*500 | 5.5 | 23 | 34 |
100TA(L1) | 31.5 | 240 | 520 | 500*500 | 5.5 | 7.5 | 10 |
100TA(L2) | 31.5 | 240 | 520 | 500*500 | 5.5 | 19 | 25 |
100TA(L3) | 31.5 | 240 | 720 | 500*450 | 7.5 | 30 | 41 |
100TB(L1) | 31.5 | 240 | 720 | 700*500 | 5.5 | 7.5 | 10 |
100TB(L2) | 31.5 | 240 | 720 | 700*500 | 5.5 | 19 | 25 |
100TB(L3) | 31.5 | 240 | 720 | 700*500 | 7.5 | 30 | 41 |
Parameters within this range reflect the wide applicability of the 350 ton hydraulic press shearing machine in different application scenarios, from small and medium-sized precision processing to large-scale industrial manufacturing.
Hydraulic Press Details Display
Main body
Main motor
Electrical part
Operation interface
Slider
Adjustable stroke
Grating ruler
Liquid crystal display
Hydraulic Press FAQ
What is the cutting capacity of the Hydraulic Press ?
The Hydraulic press hydraulic guillotine shear has a cutting capacity of up to 16mm thickness and 4000mm width for various types of metal sheets.
What materials can the Hydraulic Press cut?
The machine is designed to cut a wide range of metals, including carbon steel, stainless steel, aluminum, and other non-ferrous materials.
How is the blade clearance adjusted on the Hydraulic Press ?
The blade clearance is adjustable, allowing for precise cutting based on the thickness of the material being processed. This ensures clean, accurate cuts with minimal burr.
What are the key features of the Hydraulic Press ?
Key features include an advanced hydraulic system, a user-friendly control interface, adjustable blade clearance, and a robust construction designed for long-term durability and stable performance.
